P2 Indoor SMD LED Display



The best price above is based on a panel size of 512 x 512mm, EXW term. It is included with a receiving card and necessary cables. The production time with the aging test is 16 working days. The panel size and color can be customized.



Features:

- Ultra high definition---250,000 pixels/sq.m;
- Die casting aluminum cabinet, seamless connection;

- Lightweight, easy setup and tear down;

- Ideally suited for both fixed and rental applications;

- Rich colors and excellent contrast ratio;
- Superb color uniformity and large viewing angles;
- Low power consumption and long life span;
- Supports calibration technology on the LED lamps;
- Excellent heat dissipation on PCB board;
- IP43 protection rating to well withstand dust, moisture, static, etc;

- Easy maintenance with rear access, please let us know if you need front service;
- Brightness can be manually adjusted by software or auto-controlled by a sensor card;
- Control systems supported: Linsn, Novastar, Colorlight, etc.



Specifications:

1. Pixel Pitch: 2mm
2. Pixel Density: 250,000 pixels/sq.m
3. Pixel Configuration / LED Type: 1R1G1B, SMD1515
4. LED Module Size (L*H): 256*128mm
5. LED Module Resolution: 128*64 pixels
6. LED Display Panel Size (L*H*D): 512*512*75mm
7. LED Display Panel Resolution: 256*256 pixels
8. LED Display Panel Material: Die-casting aluminum
9. LED Display Panel Weight: 13KG
10. Brightness: ≥1,200 nits/sq.m
11. Brightness Control: 100 grades by software or auto sensor card
12. Driving Method: 1/32 scan
13. Viewing Angle: 160°H /140°V
14. Best Viewing Distance: >2M
15 Refresh Rate: ≥1.200Hz
16. GreyScale: ≥4.096 levels
17. Display Color: ≥16.7M
18. Power Consumption: max.:900W/sq.m, avg.:360W/sq.m
19. Input Voltageļ¼š110V or 230V/AC (±10%)
20. Working Voltage: DC 5V
21. Input Power Frequency: 50/60Hz
22. Protection Rating: IP43 (front/rear)
23. Operating Environment Temperature: -20°C~+50°C, Humidity: 10%~95%
24. Storage Environment Temperature:-40-50°C, Humidity: 10-90%
25. Life Span (50% brightness): ≥100,000 hours
26. Available Control System: Linsn/NovaStar/Colorlight/Mooncell/Onbon/Xixun/Lumen,etc
27. Transmission Distance: multi-mode fiber <500m, single-mode fiber <30Km, internet cable <100m
28. Operating System: Windows Series
29. Video Input (with video processor): VGA,YC,DVI,DHMI,SDI,RGB,CVBS,GD-SDI,etc
30. Compliant Standard: CE/RoHS
