RGBLINK CP 3072 Multi-screen Video Switching Station
- SKU: MLC-RGB-CP3072PRO
- 0 Units in Stock
- Brand: RGBLink
- Category:LED Video Processors
$5,000.00
- Description
- Shipping information
- Reviews
RGBLINK CP 3072PRO Multi-screen Video Switching Station
RGBLINK CP 3072 has been upgraded to CP 3072PRO. The best price above is for standard version with 4 inputs. Please contact us if you need more inputs.
CP 3072PRO integrates the console with the switch, allowing the user to seamlessly switch the video effects through the WYSIWYG interactive control panel including buttons, knobs, T-BAR, OLED panel, and indicator lights. In the shortest time, the best results are displayed in the view of the audience.
CP 3072PRO supports a variety of optional input modules with any, as well as a variety of optional output mode any setting, easy to use the push and pull lever to switch and to achieve one-click adding for graphics with special effects.
The CP 3072PRO redefines the console and switcher that can be used in any scenario thanks to its all modular design, flexible set up, easy to operate and unique shape.
Features:
- Integrated Vision Mixer & Scaler
- 5 mega pixel capacity
- Three output option modes – Dual 2K, 4Kx1K & 4K
- Select or set output resolutions to any requirement
- Dedicated source Preview output with Multiview
- Wide range of transition effects built in
- Up to 3 video layers including background for presentation Program to Preview applications
- Position, Scale, Crop video layers freely
- DSK/Key on foreground video layers
- Wide range of Masks can be applied to any foreground video layer
- Variable edge blending on foreground layers
- Additional three independent layers for OSD, LOGO and STILL
- Connect up to 9 video inputs
- Tally support built-in
- Genlock support built-in
- Modular construction – wide range of input options to choose from
- Flexible control an configuration
Specifications:
| Connectors | Inputs | Input Video: | Up to 7 inputs - select from Input Module Options |
| Outputs | PGM Output: | 2 × HDMI | |
| PST Output: | 2 × HDMI | ||
| PVW Output: | 1 × HDMI | ||
| 1 × VGA | |||
| Communication Ports | Tally | 2 × DSUB-15 | |
| Integration | DSUB-15 | ||
| Settings | USB-A | ||
| LAN | TCP/IP | ||
| Performance | Input Resolution | DVI: | VESA: 800x600 | 1024x768 | 1280x1024 | 1600x1200 | 1920x1080 | 1920x1200 | 2048x1152 |
| HDMI: | SMPTE: 480i | 576i | 720p | 1080i | 1080p | ||
| VESA: 800x600 | 1024x768 | 1280x720 | 1280x800 | 1280x960 | 1280x1024 | 1400x1050 | 1600x1200 | | |||
| 1920x1080 | 1920x1200 | 2048x1152 | |||
| SDI: | 480i | 576i |720p | 1080i | 1080p | 1080psf | ||
| VGA: | 800x600 | 1024x768 | 1280x1024 | 1600x1200 | 1920x1080 | 1920x1200 | ||
| Refresh Rates: | 23.98/24/25/29.97/30/50/59.94/60Hz | ||
| Output Resolution | Select from standard set or select user configurable | ||
| SMPTE: | 1080p | 720p | ||
| 1280x720 | 1920x1080 | |||
| VESA: | 800x600~ 2560x816 | ||
| Refresh Rates: | 23.98 | 24 | 25 | 29.97 | 30 | 50 | 59.94 | 60 | ||
| *Not all resolutions supported on VGA | |||
| Genlock | 480i | 576i | 720p@50/59.94 | 1080i@50/59.94 | 1080p@50/59.94/60 | ||
| Support Standard | SDI: | SMPTE 425M (Level A) | SMPTE 424M | SMPTE 292M | SMPTE 259M-C | DVB-ASI | |
| VGA: | VGA-UXGA | ||
| DisplayPort | 1.0 | ||
| DVI: | 1.0 | ||
| HDMI: | 1.3 | ||
| Power | Input Voltage | AC 85~264V 50/60Hz | |
| Max Power | 120W | ||
| Environment | Temperature | -25℃~55℃ | |
| Humidity | 10%~90% | ||
| Physical | Weight | 10.65kg (Net Weight) | |
| Dimensions | 462mm x 405.7mm x 170.2mm (Device Dimension) | ||
