P4 (256mm x 256mm) Indoor SMD LED Display Module for Sale

Geared with dark black SMD2121 packaged LED lamps, the P4 display panel module for sale can deliver the most vivid and deepest color depth. It is primarily created for high end LED display solution that requires extreme display quality with high contrast ratio at clearest viewing distances. Those phenomenalblack face LED module boards are widely placed at stages, live shows, retail stores, museums, theaters, sports and corporate venues, etc. The best price above includes the 128mm x 128mm LED screen module size, 16pin signal and 5V power cables.

Features:

- Ultra high definition-62,500 pixels/sq.m

- Top quality LED chips and driver IC

- Rich colors and excellent contrast ratio

- Low power consumption and long life span

- Supports calibration technology on the LED lamps

- Excellent heat dissipation on PCB board

- Superb color uniformity and large viewing angles

- IP43 protection rating to well withstand dust, moisture, static, etc

- Brightness can be manually adjusted by software or auto-controlled by sensor card

- Control systems supported: Linsn, Dbstar, Novastar, Zdec, Onbon, Xixun, Lumen, etc

Specifications:

1. Pixel Pitch: 4mm

2. Pixel Density: 62,500 pixels/sq.m

3. Pixel Configuration & LED Type: 1R1G1B, SMD2121

4. LED screen Module Size (L*H): 128*128mm

5. LED screen Module Resolution: 32*32 pixels

6. Panel Size (L*H*D)：640*640*130mm or as needed

7. Panel Resolution：160*160 pixels

8. Brightness: ≥1500 nits/sq.m

9. Brightness Control: 100 grades by software or auto sensor card

10. Driving Method: 1/16 scan

11. Viewing Angle: 145°H /145°V

12. Viewing Distance: >1.8M

13 Refresh Rate: >800Hz

14. Grey Scale: ≥4,096 levels

15. Display Color: ≥16.7M

16. Power Consumption: max.:915W/sq.m, avg.:366W/sq.m</p>

17. Input Voltage: 110~230V/AC (±10%)

18. Working Voltage: DC 5V

19. Input Power Frequency: 50/60Hz

20. Protection Rating: IP43 (front/rear)

21. Operating Environment Temperature: -20°C~+50°C, Humidity: 10%~95%

22. Storage Environment Temperature:-40-50°C, Humidity: 10-90%

23. Life Span (50% brightness): ≥100,000 hours

24. Available Control System: Linsn/NovaStar/Dbstar/Colorlight/Mooncell/Onbon/Xixun/Lumen,etc

25. Transmission Distance: multi-mode fiber <500m, single mode fiber <30Km, internet cable <100m

26. Operating System: Windows Series

27. Video Input (with video processor): VGA,YC,DVI,DHMI,SDI,RGB,CVBS,GD-SDI,etc

28. Compliant Standard: CE/RoHS
