OnBon BX-5MK1 Multi-Area Font Gate LED Controller Card

Applications:

Support Ethernet communication mode. Mainly used on industrial field, equipment,logistic warehouse and cluster system, etc.
Controller built-in font library. It could display content when users send characters, which greatly reduce the data flow and decrease the hardness on development.
Support informations dynamically refreshing: with totally 6 dynamic areas, could update informations at the same time, also could update independently;
Dynamic refreshing intervals ≥ 0.5s
BX-5MK series is based on the font library design, and suitable for the requirement of updating informations frequently. Especially for SDK.

Features:

♦ Support many kinds of application systems, and satisfy the users' special requirement;
♦ Smart control areas, abundant display functions and high performance price ratio;
♦ Good technology and best quality;
♦ Support firmware update online, which greatly save the cost on system development and updating.

Technical parameters:

Product name	ONBON BX-5MK1
Products status	The latest 5th generation products
Control area	Double color 36K: 204816 115232 76848 57664 Single color 72K:204816 204832 153648 115264
Storage capacity	2MByte
Screen types	All kinds of single and double colors led screen with 1/16,1/8,1/4,1/2 scan or static status
Software function	Screens cluster management/multi-program/multi-areas display
Program type	Normal program/Dynamic area
Program quantity	Support 128 programs,5 areas for each program
Area type	Text/Time/dynamic area
Frame mode	Most advanced colorful / magic graphics frame/Area frame
Font library	16 dot matrix/24 dot matrix/32 dot matrix
Background	Support text/image back ground
Communication mode	100M Ethernet/RS232/RS485, standard with 100M Ethernet
Time mode	Analogue clock/digital clock/timing and counting-down timer (support multi-groups)
Interface	2 nos T8 and 4 nos T12 interface
Sensor supported	Without
Bright regulation	16 grades brightness, manual and auto-timing adjustment
Power on/off	Auto-timing powered on/off
Working voltage	5V(3.5V~6.5V )
Maximum power	≤1.8W
Working temperature	-40°C~80°C
Secondary development	Provide the DLL and corresponding demos
SDK	Offer communication protocol and Demo software
