Lumen C-Power2200 Animation and Graphic LED Control Card

Lumen C-Power2200 Animation and Graphic LED Control Card

  • Model: MLC-C-Power2200
  • 1 Units in Stock
  • Shipping Weight: 1.2Kg
  • Manufactured by: Lumen
$75.00
Call for Price

  • Product Details
  • Shipping information
  • Customer Reviews

Lumen C-Power2200 Animation and Graphic LED Control Card

C-Power2200 is the compact product of the advanced animation and graphic LED screen controller C-Power3200, they are all  released by Shenzhen Lumen Electronics Co. Ltd.Bith are membesr of C-Power new platform family ,Both share the same CPU platform,both have the same computing power as C-Power5200/C-Power4200,both have larger memory, higher performance and more functions than the last Lumen generation controllers.In addition, All of C-Power family products have the same perfect second development interface and control protocol.

The only difference is that C-Power2200 cuts the size of memory and slightly reduce the display size,but the effects, functions and program types are exactly the same with C-Power3200.

Product Specifications:

Memory Font libray space:512KByte
Program size:1.5Mbyte
Total size:26MByte( 16Mbit )
Control size
(mono/RG color)
16,384 pixels
Self adjustment the size,such as 256*64, 512*32, 1024*16
Separate
window mode
Supports playing the content in different formats for each playing window.
Supports the segmentation of up to ten playing windows for each program.
Program
  • With multi-program mode. Stores up to 512 programs to the Led screen.
  • Supports animation(swf,gif), text, picture, temperature, clock, etc.
  • Transparent text and clock program can be edit to cover photo or video
  • Text program edit in any language, any font and any size, free adjust
  • With hierarchical management of programs in menu type so as to keep clear structure and convenient maintenance.
  • More than 60 effects for text and picture, such as: mosaic,snow fall, fan open, slide zebra, etc.
  • Supports programs played at the appointed period (for example: hour, minute, week )
  • Supports AVI video program NEW!
Font library 128MB font library space
The card can be stored different fond library and can be changed free, such as English,Korean,Japanese,simplified Chinese,traditional Chinese and etc.
supply font library edit tools and update tools
Affiliated features Supports sensors installed externally (32-grade brightness)
Supports environmental data programs like temperature, etc
Supports real-time clock (RTC) management and setting, support digital and analogue clock
Standard
communication
mode
USB flash disk version: USB interface
RS232/RS485 : maximum baud rate: 115200
network version: TCP/IP network interface, encrypted message transmission
GPRS version: integrate GPRS module(Dual band or Quad band)
External
communication components
Supports various wireless communication modes: GPRS/CDMA, ZigBee, RF...
InDa
remote & keyboard
Program list edit and display control by infrared controller or keyboard
Others Provides customized development interface and its manual,
the interface is same to C-Power5200
Provides demonstration program and source code for customized development
Standard software LedCenterV4.00 or above
