Sheen Color W2 LED Wireless Controller Card

Supports 640*480; 307.2 thousand pixel; and the max 256 points.

WIFI Module integration

Advantages:

Gray scale: 65536

simple operation. Do not need to do any settings, plug and play.

The hardware integration design. Reliabilty and cost down.

Stable WIFI signal strength. Signal strength is equal to the wireless router.

The software is simple to operate. The operation of WIFI terminal is as convenient as the operation of local terminal.

Product Specifications:

Type	W2
Category	WIFI asynchronous full-color control card
Pixel	640480 supporting 307.2 thousand, and best for 640480
Cascading	Support but need to connect several receiving card D10 in generlly
Gray scale	65536
Scanning mode	All Type
Communication interface	internet access/ USB port / WIFi Module
Communication way	local area network(LAN); internet; wifi; U-disk
HUB interface	general interface, supporting to connect a HUB75 or HUB40
Timing playing	support
Onboard flash	with a 4G storage, supporting to store more than 4 hours video playing
Audio	supporting USB sound card output audio interface. It's suggested that external active power amplifier device to get a much better effect.
Text transparency	recommend not use
Sensor	equipped with real-time temperature and humidity display. Supporting to adjust brightness automatically
Application	best for electronic cabn display or vehicle-mounted advertising display like bus,taxi and etc

WIFI hotspot operational program overview

The display screenterminal sets up the wireless hotspot through WIFI. And the user connects the hotspot by using a computer to control the terminal.

1. Connecting hotspot

Power on to start the control card (without connecting cable), and then choose to connect the hotspot RT2860AP in the wireless network.(WIFI hotspot do not have password while firstly use)

Change the connected IP to be obtain an IP address automatically after the connection is successful.

Normally, system will assign an IP address( 192.168.43.x) of 43 network segment to the computer:

Now please clicking the software LedGo or LedConfig to operate the control card.

2. Modify the name of the hotspot and the password

After clicking and setting, the control card will restart, and then the name of the hotspot will be changed.

Caution:

• The name of the WIFI hotspot should not be Chinese

• Please close system firewall before using the software

• Please remember the setting password, or you may to restore factory settings to empty the password.
