OnBon BX-YQ1 Asynchronous Full Color LED Controller Card

OnBon BX-YQ1 is a perfect choice for indoor/outdoor/semi-door big screens.

Application:

On-board 100M Ethernet port, SD cassette and double USB port;
Hardware configuration: Adopt A8 processor/CPU 1GHz, 512MB DRAM/4GB SD card;
Support video and audio outputting;
Support U/Flash disk/SD card;
Steady performance, simple installation and operation;
Widely used on all kinds LED full color display screens and LED Media full color screen cluster systems;
On the field of network cluster control and 3G wireless cluster control, synchronous controller cannot compare with it...

Features:

Support wide sized screens, abundant display functions;
Best techniques and quality.-40~80C wide working temperature;
Support firmware update online;
Support temperature sensor, temperature&humidity sensor and other sensors;
Support IR controller;

Technical parameters:

Product name	BX-YQ1 asynchronous full color controller
Products status	Put into the market in March, 2014.
Control area	256*256
Gray scale	65536grade
Screen types	All kinds of full colors led screen
Memory storage	With 4GByte SD card, support U/flash disk or import the programs to the SD card
Software function	Groups cluster management/multi-program editing/multi-area display/multi-language version
Program type	Normal/Shared program
Program quantity	Support 512 programs, each program with 8 areas
Area type	Graphic/subtitle/video/time/clock/timer/temperature/temperature & humidity/weather forecast
Frame mode	The colorful and active area frame
Clock mode	Dial/in Chinese and English/timer (all support multi-groups)
Communication port	Support 100M Ethernet and 3G wireless sending
Interface	2nos 50IN port, 16nos RGB data
Sensor supported	Temperature/temperature & humidity
Remote control	Select program/lock screen/brightness adjustment/power on & off/screen test
Bright regulation	8grades brightness, support manual and auto-timing adjustment/remote control
Power on/off	Support auto-timing power on & off/software power on & off/remote control
Working voltage	5V(3.5V-6V wide voltage; we suggest supply power alone to the card)
Maximum power	≤4W
Working temperature	-40°C~80°C
SDK	Support DLL, or part of the protocol
Software	LedshowYQ 2014
User manual	"LedshowYQ 2014 user manual"
