OnBon BX-5A4 LED Display Cabinet Control Card

Application:

Serial communication mode,cheap and easy to operate. dedicated for small area LED strip screen, industry production lines and all kinds of LED cluster display system.

Features:

Flexible and rich display control, high cost performance.
3.5V-6.5V wide voltage range -40°C~80°C wide work temperature
Sophisticated technology and stable quality.
Support software update online

Technical parameters:

Product name ONBON BX-5A4
Products status The latest 5th generation products
Control area Double color 64K:
3200*16 2048*32 1344*48 1024*64 896*80 768*96 640*112 512*128
448*144 384*160 352*176 320*192 304*208 288*224 272*240 256*256
Single color 128K:
3200*16 3200*32 2688*48 2048*64 1792*80 1536*96 1280*112 1024*128
896*144 768*160 704*176 640*192 608*208 576*224 544*240 512*256
Storage capacity 2MByte
Screen types All kinds of small single and double colors LED screen
Software function Screens cluster management/multi-program/multi-areas display/multi-languages
Program type Normal/shared
Program quantity Support 128 programs,24 areas for each program
Area type Image/text/animation/lunar calendar/digital clock/analogue clock
/timer/temperature/temperature & humidity
Frame mode Most advanced colorful / magic graphics frame/Area frame
Background Support text/image back ground
Communication mode S232/RS485,stanard RS232,customized RS485
Time mode Analogue clock/digital clock/timing and counting-down timer (support multi-groups)
Interface 1 nos 50 PIN
Sensor supported Supported temperature and humidity sensors
Remote control Remote control program/lock screen/brightness adjustment/power on/off /screen test
Bright regulation 16 grades brightness, manual and auto-timing adjustment/remote control
Power on/off Auto-timing powered on/off/remote control
Working voltage 5V(3.5V~6.5V )
Maximum power ≤2W
Working temperature -40°C~80°C
Adapter HUB256-T8 HUB128-T8 HUB256-T12 HUB128-T12
Secondary development  Provide the DLL and corresponding demos
