Linsn SOM205 System Embedded Module Receiver Card

Write Review

SKU: Linsn-SOM205
150 Units in Stock
Brand: Linsn
Category:LED Receiving Cards

$68.00

Description
Shipping information
Reviews

The Linsn SOM205 is an SOM (system embedded module) receiving card. Designed specifically to overcome constraints in the LED display cabinet space, physical protection, after-sales service, and pricing, the SOM205 provides a perfect solution that gives your product design a distinct competitive advantage.

Note: The SOM205 module must be used in conjunction with a companion distribution card (TP201 / TP205), which converts standard gigabit signals from the sending card into the 100M signals required by the SOM205.

Features & Capabilities

Applications & Compatibility
• Target Displays: Ideal for conventional screens as well as fine-pitch displays (P4 and below).
• System Compatibility: Fully compatible with all functions of Linsn’s 9th-generation control system.
• Driver Support: Supports common chips, PWM chips (such as the MBI5153), and other mainstream LED driver chips.

Data Output & Performance
• Signal Outputs: Supports 6 groups of parallel RGB signal data, 16 groups of serial data output, and 4-clock expansion.
• Scan Types: Supports any scan mode within 64 sweeps, as well as 595 and other serial decoding methods.
• High Refresh & Grayscale: Delivers exceptional visual performance with grayscale support up to 65,536 levels. Supports up to a 2400Hz refresh rate for fine-pitch modules (128x128 pixels, P4 and below, 32 to 64 scan) with adjustable brightness.
• Resolution Support: Maximum single-card capacity of 65,536 pixels (256 x 256).
• Advanced Visuals: Supports single-card color space transformation, pixel-by-pixel brightness and chromaticity correction, and flexible display formatting (arbitrary position offset and 4-way card rotation for shaped displays).

Wiring & Signal Transmission Innovation
• Simplified Cabling: Display signals and power can be integrated into just a 2-core ultra-5 twisted pair cable, reducing traditional 8-line cascades down to 2 lines.
• Reduced EMI Interference: Module communication utilizes only two differential lines clocked at 25MHz, significantly reducing electromagnetic interference.
• Hot Backup: Supports a 100M port hot backup function for enhanced reliability.

Design & Maintenance
• Modular Integration: Light boards and module cards can be integrated into a single modular design. During after-sales maintenance, only the specific module needs to be removed, drastically cutting down service costs.
• Shielded & Enclosed: Fully enclosed design effectively shields electromagnetic waves, making it easier to pass EMC testing and simplify waterproof casing designs.

Compliance Standards
• Fully complies with EU RoHS and EU CE-EMC standards.
