Linsn RV802/RV802D Full Color LED Screen Receiver Card

LINSN RV802 has been out of production for a long time. There are only a few pieces in our stock.

RV802 is designed for small size led screen, meet the demand of small dimensions installation design, apart from differences in size and output interface, and all other functions just the same with RV801.

Product features:

Intelligent identification card function:	Intelligent identification procedures can identify double color, full color, virtual, lighting, etc all kinds of various drivers board scanning mode and various kinds of signal , recognition rate reached 99%.
Correction function:	By point correction support single point, 2X2 points, 4X4 points and 8X8 point four correction mode, the biggest calibration 6144 points/module, red, green, blue each level of 256; By card (cabinet) used to display the between the correction of off color correction, red, green, blue each level of 256.
The refresh rate arbitrary setting, phase lock, synchronization function	set arbitrarily from 10 Hz refresh rate-3000 Hz, phase lock function to make the screen refresh lock the computer monitor refresh rate in integer times, put an end to the image rent, ensure perfect image reappearance. Phase lock synchronous range of 47 Hz-76 Hz.
65536 level (64 K) gray arbitrary setting function:	According to the situation of display customers can arbitrarily set from no gray to level 65536 (64 K), make your screen to achieve the best display effect.
Double cable heat backup function:	The A and B two ports of receiving card can be used to input or output, can be used for two computers to control a screen at the same time, when one computer have problems, another one automatically replace it, also can be used for one computer with double cable control, when one cable have problems, another one automatically take it over, making the normal work of screen to get maximum security.
Control area:	Full color 4096(4K) gray level 180HZ refresh rate,max controls 512128, twice than the sixth generation product,full color static 16384(16k)gray level 300HZ, max controls 16064(note:need driving board can be on high 30MHZ clock)
Display independent broadcasting	Display independent broadcasting, can be through the shortcut key, fast switching.
Many screens synchronization and composite function:	Support a piece of sending card controlling pieces screens, the working state of screens can be arbitrary combination, synchronous
Program online upgrade function:	If the screen receiving card program needs to be upgraded, need to open display power and update through the LED studio, no need to detach receiving card from the display.
256 level automatically brightness adjustment:	A level 256 automatic adjustment function make display brightness adjustment more effective.
Test function:	Receiving card integration test function, need not take send card can test display, slash, gray, red, green, blue, and the light, etc many types test mode.
Break the traditional ideas without dial code switch:	No dial code switch design, all Settings through the computer.
Long distance transmission:	Maximum transmission 170 meters (measured), ensure transmission 140 meters.
Supporting software:	equipped with real-time temperature and humidity display. Supporting to adjust brightness automatically

RV802 Pin Assignment:
J5 output port: 26Pin(main for serial LED changing and LED strip ) parallel
1 D C 2
3 B A 4
5 LAT CLK 6
7 OE GND 8
9 R8 R7 10
11 R6 R5 12
13 R4 R3 14
15 R2 R1 16
17 GND R16 18
19 R15 R14 20
21 R13 R12 22
23 R11 R10 24
25 R9 GND 26
J6 output port: 16Pin(main for parallel LED changing and LED strip )
1 D C 2
3 B A 4
5 OE CLK 6
7 LAT RD1 8
9 GD1 BD1 10
11 RD2 GD2 12
13 BD2 GND 14
15 GND GND 16
